Prisma Auto Flat Heat Press
Prisma Auto Flat Heat Press Machine
Sublimation Heat Press Machine

Prisma Auto Flat Heat Press

Auto/Manual Clam Slider Prisma Auto is the most popular model among our DTF Station Family, not just from the outlook but the function.
- RAMSPIN System
- RAMLOCK Quick Change System
- Pressure sensor
- Dressable Lower Platen
- Slider-out Lower Platen
- Interchangeable Control Box
- Superior Even Heat Distribution

SKU: GS-105HS
Availability: In Stock Pre order Out of stock
Categories: Equipment
Description

Prisma Auto Flat Heat Press

The Prisma Auto Heat Press is a versatile and powerful tool designed to enhance garment printing workflows.

It features a popular 16″x20″ platen size, an auto-open mechanism, a slide-out lower platen, and RAMLOCK interchangeable platens.

With these features, the Prisma Auto is the ideal press for all your printing needs.

Prisma Auto Flat Heat Press

Features

Patented “RAMSPIN” System: With self-developed “RAMSPIN” quick-change system, customers can switch between auto-open control and manual control. (Patent No.:ZL 2020 2 0858789.5)

Patented “RAMLOCK” Quick Change System: With this patent system, customer can change multiple lower platens with different sizes easily. (Patent No.:ZL 2018 2 0678795.5)

Pressure Sensor: 9-Level Pressure Scale Display for Consistent Results Every Time

Dressable Lower Platen: The special laser-cut base allows users to dress garments over the lower platen without stretching them out. Simply load the shirt onto the platen and feed the bottom of the garment through the clearance underneath the lower platen.

Slider-out Lower Platen: With slide-out lower platen, customers could put or dress garments freely without worrying about burning hands by upper heat platen during this process.

Interchangeable Control Box: With quality aviation connector, the control box can be taken off and put on easily. This helps machines maintenance.

Heat Platen: Superior evenness and speed of heating

One-for-All Solution: Compatible with Multiple Platen Sizes

Benefits

  • One press to do all the jobs that you expected!
Specification
Model Name Prisma Auto
Power Requirements 1800W, 120V,16.4A; 240V, 8.2A
Heater Size 15"x15"(381x381mm) / 16"x20"(406x508mm)
Temperature Range Max.221℃/430°F
Heating Up Time 180℃/20 minutes
Auto-open/Manual Optional
Slide-out Lower Platen Yes
Way to Change Lower platen  “Ramlock” quick change system
Pressure Display YES
Product Weight 46kg
Packaging Weight 54kg
Machine Dimensions 630x410x860mm/750x430x1000mm
Packaging Dimensions 715x500x470mm/825x495x505mm
Warranty One year warranty on the control board, Two years warranty on the entire machine, 10 years warranty on the heat platen
Suitable Users All Sublimation & DTF sheet printing users
